Reepack Model ReeFlex 250_16 Automatic Tray Sealer

Reepack Model ReeFlex 250_16 Automatic Tray Sealer

Contact us for price

Location:Corona, CA

Description

ReeFlex 250_16 automatic tray sealer is the ultimate evolution for mid to high range capacity tray sealers. The two double-chambers, fully automatic tray sealers have been completely renewed in accordance with the increasingly high standards of our valued customers. With the capability of 17 cycles per minute with sealing only, or 10-12 cycles per minute with vacuum and a gas system for MAP ( modified atmosphere packaging) configurations. The ReeFlex tray sealer is optimized for flexibility, efficiency, reliability in order to achieve the best performance and output for any processing needs. Materials Any type of tray / container of plastic material, multi-layer, foam, carton board, or aluminum can be perfectly processed with the ReeFlex tray sealing line and matching lid film- neutral or printed. RAM Manufacturing Equipment located in Corona, California, offers training, installation, service and parts for all the machines we sell. Including the Reepack Model ReeFlex 250_16 Automatic Tray Sealer and many others. Call or visit us today for more information! Call, Email or Visit at: 951-734-8152 235 Benjamin Dr. Suite 102 Corona, CA 92879 bob@ramaxwell.com Multi-functional display with touch screen and USB connection Safety device for inlet conveyor Servo driven chambers Double valve vacuum and gas system Stainless Steel Construction

Specifications

ConditionNew
Machine height75.2"
Machine width41"
Machine length depending on conveyor size175.2" / 210.6" / 250" / 282"
Length free loading area (in-feed conveyor)39.4" / 78.7" / 118.1" / 157.5'"
Free loading positions3 - 6 - 9 -12
Tray index12.5"
Height of loading conveyor36" - 37.8"
Double chamber movementElectro-Mechanical Servodrive
Machine weight excluding vacuum pumpApprox. 2650 Lbs
Max width of top web20.4"
Max diameter of web roll11.8"
Diameter of web roll mandrel3"
Vacuum pump available70 - 140 - 210 ft sq. per minute
Electrical supply230V / 60 Hz / 3 Ph
Compressed airMax 41kW / 67A
Machine cycle**Up to 17 w/ seal only / up to 10-12 w/ vacuum and MAP
